KCI V.A.C.Via Kurzanleitung Seite 5

V.A.C.Via Negative Presure Wound
™
Therapy System - Quick Reference Guide
The V.A.C.Via™ Therapy Unit is a single use, disposable V.A.C.
designed for moderate to low-severity wounds. The V.A.C.Via™ Therapy Unit has
a 7-day lifespan and a rechargeable battery. This unit provides negative pressure
at either 75mmHg or 125mmHg, and offers selection of Continuous therapy or
Dynamic Pressure Control ™ therapy. The V.A.C.Via ™
unit, one carrying case, one AC power cord, one 250cc canister and one Medium
Spiral Granufoam Dressing. Dressing kits and canisters designed specifically for the
V.A.C.Via are provided separately.
™
CAUTION: Once therapy is on for one continuous hour, the 7-day lifespan begins
(one light for each day of therapy remaining) and continues even if unit is turned off.
IMPORTANT: As with any prescription medical device, failure to
consult a physician and carefully read and follow all therapy unit and
dressing instructions and safety information prior to each use may
lead to improper product performance and the potential for serious
or fatal injury. Do not adjust therapy unit settings or perform therapy
application without directions from/or supervision by the treating
physician or caregiver.
This guide is not intended as a comprehensive resource. For additional information
concerning proper use of the V.A.C.Via ™ Therapy System and important information
including Safety Information, Cautions and Warnings, consult the Instructions for
Use located in the device packaging, and discuss with your doctor.
Upon receipt, of the V.A.C.Via Therapy Unit battery may not be fully charged.
™
Dressing Application
1
2 3
3M™ Cavilon™ Unfold Foam Place Foam
No Sting Barrier Film Not Over Wound
7
5 6
Place Drape
Trim Drape if needed Remove Layer 1
Remove Layer 2
10
11
9
Remove Bottom Place Interface Pad Remove Stabilization
Layers 1 & 2 Center Over Hole Layer
NOTE: Ensure clinician records the total number of pieces of foam used in the
wound and documents on the supplied Foam Quantity Label (attached to the
Interface Pad tubing) and in the patient's chart.
Canister Installation/Removal
® Therapy device
Starter Kits include one therapy
1
To remove canister, disconnect tubing and depress locking tab on top of
canister.
Press and Hold center of On Button for Three Seconds
(125mmHg LED Will Flash Until Pressure is Reached)
Select Pressure Setting 125mmHg (Default) or 75mmHg
(Press and Hold center for Three Seconds)
4
Trim Foam
Not Over Wound
See NOTE Below
2.5
cm
8
Select Continuous
Cut 2.5 cm Hole
Dynamic Pressure Control
(Press and Hold center for Three Seconds)
12
Initiate Therapy
3
2 4
Turn Therapy On
Therapy Settings
(Default) or
™
1
Therapy Unit Carrying Case
The V.A.C.Via
belt clip and a separate adjustable strap to allow
for versatile positioning.
CAUTION: Do not wear strap around neck.
Tubing management - the belt clip and
additional clips on each side and at the
Tubing
bottom of the carrying case provide
wrapped
a place where excess tubing may be
around clips
wrapped and stored.
Instructions for Patient
For important Safety Information, Warnings, Precautions and detailed
operating Instructions see V.A.C.Via ™ Instructions for Use (located in
the device packaging). Always consult a physician and carefully review device
instructions and Safety Information with your clinical care provider.
DAIly USe
The V.A.C.Via Therapy System is portable and small enough that it may be
™
worn beneath clothing during normal patient activities as approved by the
treating physician.
Sleeping:
• Position therapy unit so that tubing will not become kinked or pinched.
• Ensure therapy unit will not be pulled off a table or fall to the floor during
sleep.
• It is recommended to keep therapy unit plugged in and charging while
sleeping.
Showering and Bathing:
• Do not use the V.A.C.Via ™ Therapy Unit where it can fall or be pulled into
a tub, shower or sink.
• Do not reach for a product that has fallen into water. Unplug the unit
immediately if plugged into electrical source. Clamp tubing, disconnect
therapy unit from dressing and contact KCI.
• To shower, clamp tubing and disconnect from therapy unit.
• The clear drape is waterproof; patient may wash or shower with dressing
in place and the tube clamped and disconnected from the therapy unit.
• When towel drying avoid disturbing or damaging the dressing.
Cleaning:
• The V.A.C.Via ™ Therapy Unit and Carrying Case can be wiped with a damp
cloth using a mild household cleaner.
KEEP GUIDE WITH DEVICE
Carrying Case has an intergrated
™
