Do not load the instrument more than 12 times for a maximum of 12 firings per instrument. The use of the
instrument with staple line buttressing material may reduce the number of firings.
E 45 Product Family
chElon
Instrument
Code
EC45
SC45
ECLG45
Reload Product Codes Table
(For use with instrument codes listed above.)
Reload Staple
Code Leg Length
ECR45W 2.5 mm
ECR45B 3.5 mm
ECR45D 3.8 mm
ECR45G 4.1 mm
Illustration and Nomenclature (Illustration 1)
1. Staple Retaining Cap
2. Anvil Jaw
3. Cartridge Jaw
4. Reload Alignment Slot
5. Cartridge Alignment Tab
Instructions for Use
Verify compatibility of all instruments and accessories prior to using the instrument (refer to Warnings
and Precautions).
Loading the Instrument
Using sterile technique, remove the instrument and reload from their respective packages. To avoid
1
damage, do not flip the instrument or reload into the sterile field.
Description
EchElon 45 Endoscopic Linear Cutter – Straight
(does not contain a cartridge)
Compact EchElon 45 Endoscopic Linear Cutter – Straight
(does not contain a cartridge)
Long EchElon 45 Endoscopic Linear Cutter – Straight
(does not contain a cartridge)
Closed
Staple Height
1.0 mm
1.5 mm
1.8 mm
2.0 mm
Number
of Staples
70
70
70
70
4
Shaft
Length
340 mm
280 mm
440 mm
Reload Staple
Color Rows
White 6
Blue 6
Gold 6
Green 6
