27
26
Fig. 10: Example configuration: unit consisting of AES series bus coupler and I/O modules, and AV series valves
AVENTICS | Bus Coupler AES/Valve Driver AV, EtherCAT | R412018142–BAL–001–AF
30
29
28
35
26 Left end plate
27 I/O modules
28 Bus coupler
29 Transition plate
30 Pneumatic supply plate

12.2 Valve zone

The following figures show the components as illustrations and symbols. The symbol
representations are used in section 12.5 "Conversion of the valve zone" on page 100.
32
32 Valve driver (concealed)
33 Right end plate
34 Pneumatic unit, AV series
35 Electrical unit, AES series
91
Conversion of the Valve System
33
34
