11 LED Diagnosis on the Bus Coupler

The bus coupler monitors the power supplies for the electronic components and actuator control.
If they exceed or fall below a set threshold, an error signal will be generated and reported
to the controller. In addition, the status is displayed by the diagnostic LEDs.
The LEDs on the top of the bus coupler reflect the messages listed in Table 15.
Before commissioning and during operation, regularly check the bus coupler functions by
reading the LEDs.
Table 15: Meaning of the diagnostic LEDs
Designation Color State
UL (14) Green Illuminated
Red Flashes
Red Illuminated
Green/Red Off
UA (15) Green Illuminated
Red Flashes
Red Illuminated
IO/DIAG (16) Red Illuminated
Red Flashes
RUN (17) Green Illuminated
Green Isolated
flashes
Green Flashes
Green Off
S 1 (18) Green Illuminated
Green Flashes
quickly
Green Off
S 2 (19) Green Illuminated
Green Flashes
quickly
Green Off
LED Diagnosis on the Bus Coupler
Meaning
The electronics supply voltage is greater than the lower tolerance
limit (18 V DC).
The electronics supply voltage is less than the lower tolerance
limit (18 V DC) and greater than 10 V DC.
The electronics supply voltage is less than 10 V DC.
The electronics supply voltage is significantly less than 10 V DC
(limit not defined).
Actuator voltage exceeds the lower tolerance limit (21.6 V DC).
The actuator voltage is less than the lower tolerance limit
(21.6 V DC) and greater than UA-OFF.
The actuator voltage is less than UA-OFF.
Diagnostic message from module present
Valve unit incorrectly configured or backplane function error
Bus coupler status is OPERATIONAL
Bus coupler status is SAFE-OPERATIONAL
Bus coupler status is PRE-OPERATIONAL
Device is in INIT status
The physical connection between the bus coupler and network
has been detected (link established).
Data packets received (flashes for each data packet received)
The bus coupler does not have a physical connection with the
network.
The physical connection between the bus coupler and network
has been detected (link established).
Data packets received (flashes for each data packet received)
The bus coupler does not have a physical connection with the
network.
