02.2005
Number / Alarm Cause
A083 The following description refers to the 1st
CBP. For other CBs or the TB see the
CB alarm operating instructions for the CB board.
No net data or invalid net data (e.g. complete
control word STW1=0) are being received
from the DP master.
Consequence:
The process data are not passed on to the
dual port RAM. If P722 (P695) is not equal to
zero, this will cause the fault message F082 to
be tripped.
A084 The following description refers to the 1st
CBP. For other CBs or the TB see the
CB alarm operating instructions for the CB board.
The telegram traffic between the DP master
and the CBP has been interrupted (e.g. cable
break, bus cable pulled out or DP master
powered down).
Consequence:
If P722 (P695) is not equal to zero, this will
cause the fault message F082 to be tripped.
A085 The following description refers to the 1st
CBP. For other CBs or the TB see the
CB alarm operating instructions for the CB board.
The CBP does not generate this alarm!
A086 The following description refers to the 1st
CBP. For other CBs or the TB see the
CB alarm operating instructions for the CB board.
Failure of the heartbeat counter on the basic
unit. The heartbeat counter on the basic unit is
no longer being incremented. The
communication between the CBP and the
basic board is disturbed.
A087 The following description refers to the 1st
CBP. For other CBs or the TB see the
CB alarm operating instructions for the CB board.
Fault in the DPS manager software of the
CBP.
A088 See user manual for CB board
CB alarm
A089 See user manual for CB board
Alarm of the 2nd CB board corresponds to
CB alarm A81 of the 1st CB board
A090 See user manual for CB board
Alarm of the 2nd CB board corresponds to
CB alarm A82 of the 1st CB board
A091 See user manual for CB board
Alarm of the 2nd CB board corresponds to
CB alarm A83 of the 1st CB board
A092 See user manual for CB board
Alarm of the 2nd CB board corresponds to
CB alarm A84 of the 1st CB board
A093 See user manual for CB board
Alarm of the 2nd CB board corresponds to
CB alarm A85 of the 1st CB board
A094 See user manual for CB board
Alarm of the 2nd CB board corresponds to
CB alarm A86 of the 1st CB board
A095 Alarm of the 2nd CB board. Corresponds to
A87 of the 1st CB board
CB alarm
See operating instructions for CB board
Siemens AG 6SE7087-6KP60
SIMOVERT MASTERDRIVES Operating Instructions
Counter-measure
See operating instructions of the CB board
See operating instructions of the CB board
See operating instructions of the CB board
See operating instructions of the CB board
See operating instructions of the CB board
See user manual for CB board
See user manual for CB board
See user manual for CB board
See user manual for CB board
See user manual for CB board
See user manual for CB board
See user manual for CB board
See user manual for CB board
Faults and Alarms
13-23
