05.2003
P100 = ?
P095=2
P097>0
P101 = ?
P102 = ?
P104=? P105=?
P106=?
P107 = ?
P108 = ?
P109 = ?
Siemens AG 6SE7087-6KP60
SIMOVERT MASTERDRIVES
Enter the open/closed-loop control type (sheet r0 to r5)
0: v/f open-loop control + n-controller with pulse encoder
(P130 = 11)
1: v/f open-loop control
2: v/f open-loop control, textile
3: Vector control without tachometer (f-control)
4: Vector control with tachometer (n-speed)
with pulse encoder (P130 = 11)
5: Torque control (M control)
with pulse controller (P130 = 11)
For v/f control (0..2) a linear curve is set in P330 (P330 = 1:
parabolic).
The pulse encoder has a pulse number of P151 = 1024 per
revolution.
The following inputs of motor data are necessary if the motor
deviates from the converter data, if one of the vector control
types (P100 = 3, 4, 5) has been selected or if speed feedback is
used (P100 = 0). In the case of motor outputs higher than
approx. 200 kW one of the vector control types should be used.
Enter the rated motor voltage in V
as per rating plate
Enter the rated motor current in A
as per rating plate
(group drives: total of all motor currents)
IEC motor: Cos (phi) as per rating plate
NEMA motor: nominal rating [Hp]
(group drives: total of all ratings)
NEMA motor: Enter the motor efficiency in %
as per rating plate
Enter the rated motor frequency in Hz
as per rating plate
Enter the rated motor speed in rpm
as per rating plate
Enter the motor pole pair number
(is automatically calculated)
Operating Instructions
Parameterizing Steps
9-7
