06.2005
7.1

Power connections

WARNING
NOTE
7.1.1

Power connections for units with a width up to 90 mm

Protective
conductor
X3 - DC link bus
module
Siemens AG 6SE7087-6KP60
SIMOVERT MASTERDRIVES
Protective conductor
The protective conductor must be connected up both on the mains side
and on the motor side.
On account of leakage current through the interference-suppression
capacitors the following must be observed as per EN 50178
• A minimum cross-section of 10 mm
• If supply connections with cross-sections less than 10 mm
used, two protective conductors have to be connected up. The
cross-section of each of the protective conductors corresponds to
the cross-section of an outer conductor.
If the unit is mounted on a grounded mounting surface via a conductive
connection, the protective conductor cross section can be the same as
that of the phase conductor. The function of the second protective
conductor is afforded by the grounded mounting surface.
On top of the unit behind the DC link connection X3 is an extra
protective conductor connection in the form of a threaded M4 bolt.
This is used for connecting up the second protective conductor in
accordance with EN 50178.
The DC link bus module serves to supply the unit with electrical energy.
Bar Designation
3 PE3
2 D / L-
1 C / L+
Connectable cross-section: "Electro-plated copper" 3x10 mm, rounded
off according to DIN 46433 (EN 13601)
Bar 1 is at the front when installed.
Table 7-1 DC link busbars
Operating Instructions
2
Cu must be used or
Meaning
Protective conductor connection
DC link voltge -
DC link voltage +
Connecting-up
2
are
Range
DC 510 - 650 V
DC 510 - 650 V
7-5
