Siemens simovert masterdrives Betriebsanleitung Seite 250

Technical Data
Designation
Order No.
Rated voltage
• Input
• Output
Rated frequency
• Input
• Output
Rated current
• Input
• Output
Motor rated power
Auxiliary power supply
Max. aux. current requirement [A]
• Standard version at 20 V
• Maximum version at 20 V
Pulse frequency fp
Load class II to EN 60 146-1-1
Base load current
Overload cycle time
Overload current
Overload duration
Extra short-time loading
Base load current
Overload cycle time
Overload current *)
Overload duration
Loses, cooling
Efficiency η (rated operation)
Power loss (fp = 2.5 kHz)
Cooling air requirement
∆
Pressure drop p
Sound pressure levels, types of construction, dimensions, weights
Sound pressure level
Dimensions
• Width
• Height
• Depth
Weight approx.
12-4
6SE70... 21-8TP_0
[V]
[Hz]
[A]
20.8
17.5
[kW] 7.5
[V]
0.8
1.5
[kHz]
[A]
[s]
[A]
[s]
[A]
[s]
[A]
[s]
[kW] 0.17
[m³/s] 0.041
[Pa] 30
[dB(A)] 48
[mm]
135
360
260
[kg] 8.9
*) With a 1.6-fold overload in field weakening, the torque quality is reduced
due to a ripple of 300 Hz.
Table 12-3 Technical data of inverter (part 2)
Value
22-6TP_0 23-4TP_0
DC 510 (- 15 %) to 650 (+ 10 %)
3 AC 0 up to rated input voltage x 0.75
---
0 ... 500
30.3 40.5
25.5 34.0
11.0 15.0
DC 24 (20 - 30)
1.7 to 16.0 (see fig. "Derating curves")
0.91 x rated output current
300
1.36 x rated output current
60
0.91 x rated output current
300
1.6 x rated output current
30
0.22 0.30
0.041 0.061
30 30
48 59
135 180
360 360
260 260
9.0 12.7
Operating Instructions
06.2005
23-8TP_0
44.6
37.5
18.5
0.8
1.7
0.35
0.061
30
59
180
360
260
12.9
