DC link bus module X3
Safe Stop (option) X533
PMU
External DC24 V supply,
RS485 (USS) X100
Bus terminating
resistor (USS) S1
Terminal strip X101
RS232/RS485 (USS) X103
Motor connection X2
Siemens AG 6SE7087-6KP60
SIMOVERT MASTERDRIVES
SIEMENS
P
A
S1
X101 B
X103 C
Fig. 7-2 Connection overview of units 135 mm wide
Operating Instructions
PE3
−
+
Slot A
Slot B
Terminal strip
X102
Encoder connection
X104
Connecting-up
