3R33: Recommendation for mobility degree 1
(indoor walkers)
Approved for a patient with a weight of up to 125 kg
3R17: Recommendation for mobility degree 1
(indoor walkers)
Approved for a patient with a weight of up to 150 kg
The Ottobock MOBIS is not intended to be used as a guide to obtaining reimbursement
for prosthetic components in the USA.
Due to the small space requirements above the axis it is suitable for long above knee amputation
levels. Further, the 3R17 and 3R33 Knee Joints can be interchanged with our 3R20, 3R36, 3R22
and 3R34 Knee Joints.
Attention!
Please avoid exposing prosthetic components to surroundings that corrode metal parts,
for example, freshwater, saltwater, acids and other liquids. Using this medical product
in such environmental conditions will render all claims against Otto Bock HealthCare
null and void.
Please inform your patients.
2.2 Service life
CAUTION
Reuse on another patient
Fall due to loss of functionality as well as damage to the product
f Only use the product for a single patient�
f Inform the patient.
This prosthetic component has been tested by the manufacturer for 1 million load cycles.
For patients with mobility grade 1, this corresponds to a service life of a maximum of 5 years.
2.3 Construction
The Upper Joint Section (1) is connected to the Lower Joint Section (2) by the Axis (8). Medio-
lateral movement is prevented by Ball Thrust Bearings (7). The axis is a hardened, precision
ground bolt and is mounted in special bushings. The Nut for Axis (9) is serrated and secured with
a Safety Plate (10).
2.4 Extension assist
The Extension Assist consists of two Spring Guide Pins (14), two Spring Guide Housings
(13) and two Compression Springs (12). The primary function of this unit is to aid the knee in
reaching full extension to help insure that the lock engages.
