INFORMATION
Last update: 2016-03-16
f Please read this document carefully before using the product.
f Follow the safety instructions to avoid injuries and damage to the product.
f Instruct the user in the proper and safe use of the product.
f Please keep this document in a safe place.
1 Components (fig. 1)
(for 3R33 in brackets)
(1) 4G32=2 (4G99=2) Upper Joint Section
(2) 4G33 (4G98) Lower Joint Section
(3) 4G34 Extension Stop
(4) 4H45 Rubber Bumper
(5) 506G3=M8×20 Set Screw
(6) 2H31=14×12×15 Joint Axis Bushing
(7) 4Y10 Thrust Bearing
(8) 4A42=46 Axis
(9) 4A43 Nut for Axis
(10) 4Z30 Safety Plate
(11) 501S27=M4×5 Oval Head Screw
(12) 513D35=60×7.6×1.2 Compression
Spring
(13) 4V102 Spring Guide Housing
(14) 4V101 Spring Guide Pin
(15) 504R1=2.5×20 Guide Pin
1.1 Single-component packs
4D10 Single-component pack for 3R33 and 3R17 (fig.1,
Consisting of: 1 plastic knee cap, 2 bushings, 2 spring bushings, 1 guide pin, 1 compression
spring, 1 set screw, 1 safety plate, 1 oval head screw, 1 rubber bumper, 2 thrust bearings,
2 compression springs, 2 spring guide pins, 2 lock screws, 1 spring guide housing.
4D11 Single-component pack for 3R33 and 3R17 (fig.1,
Consisting of: 1 lock unit, 1 short threaded fitting, 1 cable clamp and perlon cord.
2 Description
2.1 Application and recommendations
The monocentric Modular Knee Joints 3R33 (titanium) and 3R17 (stainless steel) with adjustable
manual lock are to be exclusively used for the prosthetic fitting of amputations of the lower limb.
Field of application according to the Ottobock Mobility System MOBIS
8 | Ottobock
(16) 4G35 Lock Cam
(17) 4G36 Lock Lever
(18) 4A46 Axis Pin
(19) 4A47 Axis Pin
(20) 4A51 Axis Pin
(21) 4V104 Spring Guide Housing
(22) 513D18=4.7×31 Compression Spring
(23) 501S22=8×M3.5 Lock Screw
(24) 21A18=2 Perlon Cord
(25) 21A12 Threaded Fitting, short
(26) 21A8 Cable Clamp
(27) 516S3 Button Head Screw, nickel plated
(28) 4F17=N Lock Handle, complete
(29) 4G66 Plastic Knee Cap
(30) 501Z2=M4×8 Cap Screw
)
)
