Connection of the communication accessories

9. Connection of the communication accessories
This chapter explains the process for wiring the communication accessories to the unit.
There are several ways to achieve this communication with these units:
RS-485
Ethernet TCP
GSM/GPRS
See the corresponding communications accessories manual for further information.
Read carefully before starting the connection process.
9.1. Safety instructions for connecting the communications
accessories
Refer to Section "3. Safety" and the safety paragraph in this section before operating the equipment.
Make sure there is no voltage present on the unit before carrying out any connections. Once the
inverter is switched off, wait at least 10 minutes until internal capabilities are fully discharged.
Ingeteam accepts no liability for any damages caused by incorrect connection.
Use the Personal Protective Equipment specified in the section "3.2. Personal Protective Equipment
(PPE)".

9.2. Connecting the communication accessories

To connect the different communication accessories you must insert the communication card into connectors J11
and J12. Do the wiring as indicated in the manual corresponding to this communication accessory and bring this
wiring out through one of the packing glands intended for communications.
