6. Installing the unit

Before installing the unit, the packaging must be removed, taking special care not to damage the housing.
Check that there is no condensation inside the packaging. If there are signs of condensation, you must not install
the unit until you are sure it is completely dry.
All installation operations must comply with current regulations.

6.1. General requirements for installation

• The environment of the unit must be appropriate and meet the guidelines described in Chapter "5.
Preparation for installing the unit". Additionally, the parts used in the rest of the installation must be
compatible with the unit and comply with the applicable legislation.
• Ventilation and the space for work, which must be suitable for maintenance tasks according to the
applicable regulations in force.
• The external connection devices, which must be suitable and sufficiently close as set forth in current
regulations.
• The cables must be of the appropriate gauge for the maximum current.

6.2. Attaching the unit to the wall

These units have a system for securing them to the wall using plates. The steps for fixing the unit properly are as
follows.
The weight of the unit must be taken into account (see section "2.6. Specification table").
1. Attach the three fastening plates at the top using the screws supplied.
2. Attach the hooks to the wall using stainless steel fasteners that are appropriate for its material.
