2.6. Specification table

Maximum number of connectable strings
Maximum number of measurable channels
Maximum current per string
Maximum total current
Number of protection fuses
Maximum voltage
Input connectors
Output connectors
Communication connections
Operating temperature
Protection class
Ground connector
Size and weight
15 kg.

2.7. Description of cable inlets

A. DC output toward the inverter (M50).
B. Ground (M16).
C. Multipurpose/communications (M16).
D. DC input from the PV array (type 4 quick connectors or M12 packing gland).
E. Connector of the polarity verifier.
F. LED of the polarity verifier.
46

String Control 160

PV connectors type 4 (6 mm
(mm)
E F
A
B C
String Control 320
16
16
10 ADC 20 ADC
160 ADC 320 ADC
16
1000 VDC
) or M12 packing gland (up to 10 mm
2
M50 packing gland (up to 300 mm
RS-485, Ethernet, GSM/GPRS
-20 ºC ~ 65 ºC
IP65
M16 packing gland (up to 16 mm
AAS2011IQM01_ - Installation and usage manual
Unit description
)
2
)
2
2 )
D
