Preparation for installing the unit

5. Preparation for installing the unit
When deciding the location of the unit and planning your installation, you must follow a set of guidelines based on
the specifications of the unit. These guidelines are summarised in this chapter.

5.1. Environment

• Place the units in a place that is accessible for installation and maintenance work.
• Avoid corrosive environments that may affect the proper operation of the unit.
• Never place any object on top of the unit.
• Ingeteam recommends protecting the units from direct sunlight.

5.2. Environmental conditions

Environmental conditions must be taken into account when choosing the location of the unit.
Maximum relative humidity without condensation
It should be borne in mind that moderate condensation may occasionally occur as a consequence of temperature
variations. For this reason, apart from the unit's own protection, it is necessary to monitor these units once they
have been started up on sites where the conditions described above are not expected to be present.
In the event of condensation, never apply voltage to the unit.

5.3. Supporting Surface and Fastening

To guarantee good heat evacuation and promote sealing, the units must be placed on a perfectly vertical wall or,
failing this, with a slight slope of a maximum of ± 10º from vertical.
Reserve a solid wall to which to attach the unit. It must be possible to drill the wall and fit suitable fixing elements
to support the unit's weight.
AAS2011IQM01_ - Installation and usage manual
Environmental conditions
Minimum temperature
Minimum surrounding air temperature
Maximum surrounding air temperature
−20 ºC
−20 ºC
65 ºC
95%
90º ± 10º
