6. Product information

6.6 Electric cylinder overview diagram

16
15
14
13
12
11
10
9 8
1 Hood
2 Linch pin
3 Limit switch unit
4 Push rod
5 Guide tube
6 Suspension "front"
7 Adjustment without power (optional)
8 Bearing
9 Suspension "rear"
10 O ring seal
11 Worm gear shaft
12 Trapezium spindle
13 Gear housing
14 Auger
15 Motor
16 Seal
42
.
1
2
3
5
6
7
4
