7.5.3 Fitting and installation

Never pretension the Bowden cable when it is in a free state otherwise there is a risk
of releasing the push rod.
Thereafter, the electric cylinder will not fulfil its function in operation.
There is a risk of damage when applying a little force.
The Bowden cable is mounted onto the electric cylinder by the manufacturer.
The Bowden cable is mounted opposite to the electric cylinder.
The play can be reduced using the adjustment screw.

7.5.4 Overview of the Bowden cable unit

1
2
3
4
5
6
1 Cylinder pin
2 Mounting attachment
3 Bowden cable housing
4 O ring seal
5 Eccentric wheel
6 Cylinder pin
7. Life phases
49
