6.6 Overview diagram of the lifting column

1 Fixing plates "Push rod side"
2 Push rod
3 Inner profile
4 Centre profile
5 Slider
6 Outer profile
7 Trapezium spindle
8 Gear housing
9 Limit switch unit
10 DC motor with screw
11 Seal
12 Fixing plate "motor side"
13 Worm gear with two bearings
14 Hood
15 Linch pin
6. Product information
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
