7.6.1 Installation procedure / installation sequence

•
Hang the rear suspension onto the "counter-piece".
The counter-piece must not be able to be twisted. The electric cylinder must be able
to be rotated in the direction of the arrow (see graphic).
•
Remove the adhesive safety tape.
The push rod must not be rotated.
•
Fix the suspension at the "front".
The counter-piece must not be able to be twisted. The electric cylinder must be able
to be rotated in the direction of the arrow (see graphic).
7. Life phases
51
