KIOX 400C, SYSTEM CONTROLLER & MINI REMOTE FUNCTION
(8) (9)
(8) (9)
(1) Mini Remote operating unit
(2) Kiox 400C
(3)System Controller
(4) LED indicator lamp
(5) Button for increasing support level +/bike lights
(6) Select Button
(7) Button for decreasing support level -/walk assistance
(8) Holder
(9) Fastening screw for holder
pivotcycles.com
(4)
(5)
(6)
(1)
(7)
(4)
(5)
(6)
(1)
(7)
info@pivotcycles.com
(10) Protective cap for charging connection
(11) Charging connection
(12) On/off button
(13) Display Screen
(14) Ambient light sensor
(15) Mode button
(16) LEDs for battery charge indicator
(17) Fastening Screw
(18) Riding Mode LED
