KLEINTEILE-LISTE

Hardware
NUMmER TEILENUMMER
3 FP-CVR-SLTV3-SKD-V1-R1
4 FP-UDH-TA-12MM-BLK-V2-R1
5 FP-UDH-TA-12MM-BLK-V2-R1
6 FP-UDH-TA-12MM-BLK-V2-R1
7 FP-DRO-SWINGER-8MM-DS-V1
8 FP-BLT-BTN-M6*14-V1
9 FP-WSH-M6-BLK-V1-R1
10 FP-SCW-SKT-M5*6-V1
11 FP-DRO-FLIPCHIP-8MM-NDS-V1
12 FP-DRO-SWINGER-ORING-NDS-V1
13 FP-SCW-FLIPCHIP-M4*6-NDS-V1
14 FP-BRK-SWINGER-BRKT-200MM-V1
15 FP-WSH-M6-CONCAVE-V1
16 FP-WSH-M6-CONVEX-V1
17 FP-SCW-SCK-M6*32-V2-R1
18 FP-SCW-SCK-M6*30-V2-R1
19 FP-GAP-SWINGER-FILL-V1
20 FP-LNK-UL-83MM-V1-R1
21 FP-LNK-LL-50MM-V4-R1
22 FP-BRG-6902-LLUMAXECN-BO
23 FP-BRG-6902-LLUMAX-BO
24 FP-BRG-6900-LLUMAXE-BO
25 FP-BLT-M8*12-V2-R1
26 FP-NUT-FLIPCHIP-8MM-DS-V1-R1
27 FP-NUT-FLIPCHIP-8MM-NDS-V1-R1
28 FP-BLT-M14*20-BLK-V2-R2
29 FP-BLT-M10*16.5-BLK-V1
30 FP-BLT-M14*20-BLK-V3-R2
31 FP-NUT-FLIPCHIP-8.5MM-RT-V1-R1
32 FP-WSH-SPC-15I*25O*3W
33 FP-CLM-MECH-FRM-V1
34 FP-CVR-MECH-FRM-V2
35 FP-SCW-FLT-M3*10-BLK
36 FP-CLM-PORT-SINGLE-V1-R1
37 FP-SCW-FLT-M3*15-BLK
38 FP-MNT-FRNT-BATT-BDU38-V2-R1
39 FP-MNT-REAR-BATT-BDU38-V2-R1
40 FP-SCW-SCK-M4*10-V1-R1-BLK
41 FP-BLT-M6*16-V1-R1
42 FP-MNT-SLTV3-BATT-V1- R1
43 FP-SCW-FLT-M3*10-BLK
44 FP-BUSH-M6*9*5-V1-R4
45 FP-SCW-SCK-M6*16-BLK-V1-R1
46 FP-CLP-BATT-CHG-V1-R1
47 FP-MNT-BATT-CHG-V1-R1
48 FP-GKT-BATT-CHG-V2-R1
49 FP-CVR-BATT-CHG-V1-R1
50 F04N.002.663
51 FP-MNT-CG-V4
52 CH -CM1 UP PT-22
53 CH -CM1 UP PT-22
54 CH -CM1 UP PT-22
55 FP-CG-CLM-V1
56 FP-SCW-FLT-M5*12-BLK
57 FP-INS-ADJ-STA-V1-R1
58 FP-CLM-ADJ-STA-V1-R1
59 FP-BLT-M5*32-V1-R1
60 FP-WSH-5I*8O*1W-V1-R1
61 FP-CVR-ADJ-STA-V1-R1
62 FP-GDE-WIRE-PLATE-V2-R1
63 FP-BLT-M10*8.5-V1-R1
64 FP-SCW-BTN-M5*8
65 FP-BLT-BTN-M5*12-V1-R1-BLK
66 FP-PRO-SLTV3-DT-V1-R1
67 FP-PRO-SLTV3-DTU-V1-R1
68 FP-PRO-SLTV3-CS-V1-R1
69 FP-PRO-SLTV3-SS-V1-R1
70 FP-PRO-SLTV3-UR-V1-R1
71 FP-BLT-M8*80-BLK-V1-R1
72 FP-WSH-8I*21O*1.5W-BLK-V1-R1
73 FP-SPC-BDU38-NDS-NRRW-V1-R1
74 FP-GDE-CBL-BDU38-V1-R1
75 FP-SCW-BTN-M6*12-V1-R1-BLK
76 FP-CVR-ADP-BSC-V1-R1
77 FP-CBL-BT-BSC-V1-R1
78 FP-PAD-INT-CABLE-ROUTE-V1
79 FP-BATT-STRAP-V1
80 FP-SCW-SET-M5*8-BLK
pivotcycles.com
BESCHREIBUNG
Shuttle Skid Plate, BDU38 with Removeable Battery
Universal Rear Derailleur Hanger
Universal Rear Derailleur Hanger Bolt
Universal Rear Derailleur Hanger Washer
Swinger UDH Dropout DS
Swinger Dropout Mounting Bolts
Swinger Dropout Mounting Bolt Washers
Swinger UDH Stopper Bolt (Short Position)
Swinger Dropout NDS Flip Chip
Swinger Dropout NDS O-ring
M4x6 NDS Flip Chip Screw
Swinger Brake Bracket
M6 Spherical Washer (Concave)
M6 Spherical Washer (Convex)
M6x32 Sockethead Screw V2
M6x30 Sockethead Screw V2
Swinger Frame Gap Filler (Long Position)
83mm Upper Link
50mm Out-to-In Lower Link
28mm 6902 Extended Bearing - Black Oxide
28mm 6902 Standard Bearing - Black Oxide
22mm 6900 Ext'd Bearing - Black Oxide
M8 Shock Bolt for Shock Tab Flip Chip
Shock Tab Flip Chip (DS)
Shock Tab Flip Chip (NDS)
M14x20 Link Bolt
M10 Trunnion Mount Bolt
M14x20 Flip Chip Bolt
8.5mm Flip Chip
M14x3mm Flip Chip Spacer
Internal Routing Cable Clamp
Internal Routing Hole Cover
M3x10 Cable Port Screw
Dual Port - Single Clamp
Dual Port Clamp Screw Black
Bosch 800Wh PT Front Battery Bracket
Bosch 800Wh PT Rear Battery Bracket
M4x10 Sockethead Bolt - Black
Battery Bracket Mounting Bolt
Battery Bracket Mounting Plate
Battery Bracket Plate Bolt
M6 Bushing for Rear Skid Plate bolts
M6x16 Rear Skid Plate Bolts
Bosch Charger Terminal Clip
Bosch Charger Mounting Plate
Bosch Charger Hinge Gasket
Bosch Charger Top Cap
M3x14 Charging Port Mounting Screws
Chain Guide Mounting Plate
Upper Chain Guide
M5 Locknut
M5x22 Sockethead Screw
Chain Guide Cable Clamp
M5x12 Flat Head CG Mounting Screw
Adjustable STA Insert
Adjustable STA Clamp
Adjustable STA Clamp Bolt
Adjustable STA M5 Washer
Adjustable STA Cover
Internal Routing Plate
Internal Routing Plate Bolt
M5x8 Button Head Bolts Black
Top Tube Tool Bolts (SM/MD)
SLTv3 Downtube Protector
SLTv3 Downtube Protector Top
SLTv3 Chainstay Protector
SLTv3 Seatstay Protector
SLTv3 Upright Protector
Bosch BDU38 Bolt M8x80
Bosch BDU38 Washer
Bosch BDU38 Narrow Spacer
Bosch BDU38 Cable Guide
M6x12 Cable Guide Mounting Screw
Bosch Adapter Cover
Bosch Cable Boot
Internal Routing Plate Pad
Battery Bracket Strap
M5x8 Set Screw
info@pivotcycles.com
DREHMOMENT
25 Nm (18 lb·ft)
8 Nm (5.9 lb·ft)
5 Nm (3.69 lb·ft)
8 Nm (5.9 lb·ft)
8 Nm (5.9 lb·ft)
13 Nm (10 lb·ft)
35 Nm (27 lb·ft)
13 Nm (10 lb·ft)
35 Nm (27 lb·ft)
8 Nm (5.9 lb·ft)
8 Nm (5.9 lb·ft)
30 Nm (22 lb·ft)
1.877.857.4868
*
L
snug
R
R
R
G / L
g
g
L
L
L
g
g
snug y
g
snug y
g
l
snug
y
g
G/l
g
snug
16
