Presentation

1. Control panel

WIFI signal
Rapid access to boost
and absence modes
Back
Rapid access to boost
and absence modes

2. Description of pictograms

Amount of hot water
Boost in progress
Water temperature
middle of the tank
Smart Grid (2 displays)
Installation
Emergency mode
Use Maintenance
Use
Warranty
Setpoint
Indicator light:
- Red: amount of hot water
available
- Moving: heating in progress

Menu

Rapid access to the water
temperature in the middle
of the tank
Absence recorded
Absence in progress
Anti-Legionella cycle
PV
Off-peak hours
ECO+
