7. Spare parts list

3
12
14
13
30
29
28
22
27
1 Vents
2 Top cover
3 Rear cover
4 Front cover
5 Screw caps
6 Volute assembly
7 Fan
8 Fan sheet metal roof
9 Volute elastic
10 15µF capacitor
Installation
1
2
11
23
24
25
26
11 Hot gas valve coil
12 Compressor
13 Compressor jacket
14 Jacket cover
15 Column support rail
16 Front column
17 Column bottom plug
18 Column top plug
19 Hybrid ACI flange
20 Heating element
Use
9
8
4
19 20
15
Maintenance
10
6
7
5
22
16
17
21 Interface assembly
22 Control board
23 Electric heating element wiring
24 Supply wiring
25 Heat pump wiring
26 Fan wiring
27 Heat pump sensor wiring
28 Interface wiring
29 Water sensor wiring 1
30 ACI wiring
Warranty
18
21
