6. Dimensions/structure

Ref MODEL
A Condensate outlet
B Total height
C Cold water inlet
D Hot water outlet
E Total width
E Total depth
G Outlet centre distance
H Exchanger inlet
I Water recirculation inlet
Dimensions (mm)
Installation
200 L C
1190
1716
451
963
716
826
Use
B
A
240 L 270 L C
1380 1530
1906 2056
451 451
1153 1303
600
651
280
716 716
826 826
Maintenance
E
Warranty
D
I
H
C
E
G
45°
