Presentation
Remove the covers and
4
unscrew the 4 screws on the
front cover of the heat pump.
We recommend using a 2x0.75 mm² multi-strand cable with crimped ferrules (not supplied).
Route the cable through the
7
passage specifically designed for
access to the PCB.
Installation
Tilt the cover forward.
5
Screw the
8
appropriate connector depending
on the equipment connected.
Use Maintenance
T1 : Fan
I2: Smart Grid
I1 : Off-peak or
Smart Grid
CS: Boiler
cable to the
Warranty
6 Loosen the cable clamp
on the rear cover to pass the
optional equipment cable
(not supplied) through it.
Lock the cable clamp and
9
repeat the steps in reverse
order to close the product.
