b) Seat the refrigerating compartment guard gasket (8) inside the compartment guard (9).
c) Slide the dedicated O-rings (17 – size 11x2) onto the valve stem (10).
d) CAUTION! For model
e) Align the resulting assembly with the opening in the opening of the refrigerating compartment guard (9)
and install the assembly in the opening.
f) Install the dispenser levers (12) by inserting them into the holes in the valve stems (10). Secure the
assembly using the cotter pin (13).
g) CAUTION! For model
dispenser lid (16) turning it clockwise to detach. Install the gasket (15) inside of the detached part.
Reinstall the detached parts.
h) Attach the resulting assembly to the front panel of the appliance. Do this by passing the integrated
locating pins through the holes in the refrigerating compartment guard (9). Secure the with the fasteners
(14) included.
i) Install the drip tray by sliding it into its receptacle under the dispenser cluster.
j) Disassembly is done in reverse order of assembly.

3.3. Operating the appliance

Before operating this appliance, verify the installation process has been correctly done and connect the
power cord plug to a mains outlet. Refer to the appliance parameters and functions. Turn on the appliance
and set the desired parameters as described below. Start the appliance by turning the power switch (f) ON.
When done, turn the power switch (f) OFF and unplug the appliance from the mains.
3.3.1. CLEANING THE APPLIANCE COMPONENTS
Before operating the appliance and finishing the operation, always run the cleaning of the refrigerating bin,
the refrigerating compartment and its parts. The procedure:
a) Fill the refrigerating bin (1) with water.
b) On the control panel, press the refrigerating compartment wash on/off key ("WASH"). The LCD shows
the stirrer run icon (I). The appliance beeps shortly.
c) A correct cleaning cycle needs at least 3 minutes to run.
d) When done cleaning, stop the cleaning mode by switching the refrigerating compartment wash on/off
key ("WASH").
e) Empty the appliance by operating the dispenser lever(s) (12).
f) Repeat the cleaning steps above 2-3 times.
g) Clean piston
EN
: Slide the dedicated gasket (18) onto the mid stem of the valve.
: Install the dispenser gasket (15). Do this by removing the
1. Remove Stem O-ring
