The specified noise emission values have been measured
in accordance with a standardised test procedure and can
be used to compare one power tool with another.
The specified device emissions values can also be used
for an initial estimation of the load.
WARNING
The noise emission values can vary from the
specified values during the actual use of the
power tool, depending on the type and the
manner in which the electric tool is used, and
in particular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8 Assembly
ATTENTION
Always make sure the product is fully assembled
before commissioning!
WARNING
Pull out the mains plug before carrying out
any setting, servicing or repair work!
Tool required:
• 1 x open-ended spanner, AF 8/10 mm* (A)
• 1 x Allen key 3 mm* (B)
• 1 x Allen key 4 mm* (C)
• 1 x Allen key 5 mm* (D)
• 1 x Allen key 6 mm* (E)
* = may not be included in the scope of delivery!
Note:
You can store the tool supplied on the magnetic strip on
the product head.
8.1 Assembling the saw table (8)
(Fig. 1, 3, 4, 5, 6, 8)
Note:
The saw table must be adjusted before initial commission-
ing and after each saw table disassembly.
1. Extend the saw table (8) as described under 10.1.
2. Guide the saw table (8) over the band saw blade (6).
3. The scale pointer (15) must be released and must not
point upwards. Use a 4 mm Allen key.
4. Place the recess of the degree scale (14) in the two
guides on the frame (21).
Ensure that the toothing of the saw table (8) engages
with the toothing of the knurled nut (19) on the frame
(21).
5. Attach the saw table (8) with the clamping plate (20),
the two Allen screws (F), the washers (G) and the
snap ring washers (H) to the respective mounting
holes on the frame (21).
Use a 5 mm Allen key.
6. Fit the clamping lever (8a) in the centre mounting
hole.
Do not tighten the clamping lever (8a) yet.
7. Set the scale pointer (15) so that it points to the de-
gree scale.
Use a 4 mm Allen key.
8. Adjust the saw table (8) to 0° as described under 8.2.
9. Tighten the clamping lever (8a) to fix the saw table (8)
in place. Tighten the two Allen screws (F).
Use a 5 mm Allen key.
10. If necessary, readjust the scale pointer (15) and set it
to 0°.
11. To stiffen the saw table (8), fit the hexagon screw (K)
with the wing nut (L).
8.2 Adjusting the saw table (8) to 90°
(Fig. 7)
1. Adjust the saw table (8) horizontal to 0°.
2. Check the end stop screw (22) and the counternut
(22a) for firm seating and tighten if necessary. Use an
open-ended spanner AF 8/10 (A).
3. If the saw table (8) is not adjusted at a right-angle to
the band saw blade (6), the end stop screw (22) must
be readjusted.
