2 Product description (Fig. 1-24)
1. On/off switch
1a. STOP switch
2. Clamping screw
3. Magnetic plate
4. Clamping nut
5. Band saw blade guard
6. Band saw blade
7. Transverse cutting gauge
7a. Knurled nut (mitre gauge)
7b. Scale pointer (mitre gauge)
8. Saw table
8a. Clamping lever
9. Foot
10. Parallel stop
10a. Clamping bar
10b. Clamping screw (parallel stop)
11. Housing doors
11a. Safety switch
11b. Allen screw (housing door)
12. Adjustment handle (top band wheel)
12a. Wing nut (top band wheel)
13. Push stick
14. Graduated scale (pivot range)
15. Scale pointer (swivelling range)
16. Engine
17. Suction port
18. Locking handle
19. knurled nut
20. Clamping plate
21. Main frame
22. End stop screw (saw table adjustment)
22a. Counternut (saw table adjustment)
23. Top band wheel
24. Running surfaces (band saw blade)
25. Bottom band wheel
26. Top saw band guide
27. Support bearing
27a. Rear upper support bearing
27b. Grub screw
27c. Upper lateral support bearing
27d. Grub screw
27e. Rear lower support bearing
27f. Grub screw
27g. Lower lateral support bearing
27h. Grub screw
28. Top retainer
28a. Screw (top retainer)
29. Belt
29a. Belt tensioning screw
30. Drive belt pulley
31. Band wheel pulley
32. Table inlay
32a. Philips screw (table inlay)
33. Band wheel circlip
34. Band wheel shaft
3 Scope of delivery (Fig. 2)
Item QuantityDesignation
8. 1 x Saw table
6. 1 x Band saw blade (pre-assembled)
10. 1 x Parallel stop
13. 1 x Push stick
18. 1 x Locking handle
20. 1 x Clamping plate
A. 1 x Open-ended spanner, size 8/10
B. 1 x
C. 1 x
D. 1 x
E. 1 x
F. 2 x
G. 2 x
H. 2 x
I. 1 x
J. 1 x
K. 1 x
L. 1 x
1 x
1 x
4 Proper use
The band saw is used for the longitudinal and transverse
cutting of timbers or wood-like workpieces. Round materi-
als may only be cut using suitable holding devices.
WARNING
Do not use the product to cut materials other than those
described in the operating manual.
WARNING
The supplied band saw blade is only intended for the
sawing of wood! Do not use this blade for sawing fire-
wood!
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
Only suitable band saw blades may be used for the prod-
uct.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
www.scheppach.com
Allen key, 3 mm
Allen key, 4 mm
Allen key, 5 mm
Allen key, 6 mm
Allen screws (M6x12 mm)
Washer (M6)
Snap ring (M6)
Allen screw (M6x25 mm)
Nut (M6)
Hexagon screw (M6x40 mm)
Wing nut (M6)
Band saw
Operating manual
