Data transfer properties and technical data
Data transmissi-
Transmission technology
on properties
Network topology
Medium
Transmission rate
Bus connection
Process data width
Process data format
Safety features
If there is no data transmission, all inputs and outputs are reset and the power
source goes into „Stop". Once data transmission has been re-established, the fol-
lowing signals resume the process:
-
-
AB DeviceNet
Power supply
Enterprise tech-
Current input
nical data
Position on the rear of the power
sources:
Protection
Configuration interface
36
"Robot ready" signal
„Source error reset" signal
Fibre optic cable
Polymer fibre (980/1000 μm)
1 - 40 m between two stations
500 kBaud / 2 MBaud
96 bits (standard configuration)
24 V DC +/- 10%
400 mA (typical)
TS 4000 / 5000
TPS 3200 / 4000 / 5000
Via field bus configuration module
Ring
FSMA
Motorola
IP23
