Connecting and configuring AB Interbus FSMA
General remarks
Connecting and configuring the AB Interbus FSMA interface is performed on the
Anybus-S Interbus Fibre Optic bus module.
Safety
Danger from incorrect operation and work that is not carried out properly.
This can result in serious personal injury and damage to property.
▶
▶
▶
Danger from electrical current.
This can result in serious personal injury and damage to property.
▶
▶
▶
Connections,
settings and in-
dicators on the
Anybus S Inter-
bus Fibre Optic
bus module
(1)
(2)
(3)
(4)
30
WARNING!
All the work and functions described in this document must only be carried
out by technically trained and qualified personnel.
Read and understand this document in full.
Read and understand all safety rules and user documentation for this device
and all system components.
WARNING!
Before starting work, switch off all devices and components involved and dis-
connect them from the grid.
Secure all devices and components involved so they cannot be switched back
on.
After opening the device, use a suitable measuring instrument to check that
electrically charged components (such as capacitors) have been discharged.
(2)
(3)
(4)
(5)
Interface to UBST 1 board
Fibre optic connection bus IN
Fibre optic connection bus OUT
Baud rate selector switch
(1)
(5)
Bus voltage OK indicator
(6)
LED indicator
(7)
Anybus-S status indicator
(7)
(6)
