Interface AB In-
terbus FSMA an-
schließen
Bus IN and bus OUT pin assignments
Setting the data
The Anybus-S Interbus Fibre Optic bus module supports the following data
transmission
transmission speeds (baud rates):
speed (baud ra-
-
te)
-
Baud rate selector switch: jumper position
(1)
(2)
Bus OUT
Bus IN
2 Mbit/s
500 kbit/s
2 Mbit/s
500 kbit/s
Connect LocalNet plug on inter-
1
mediate hosepack to LocalNet
connection (1)
Remove interface cover (2)
2
Remove one of the five blanking
3
covers
Feed Interbus data line fibre optic
4
cable through the opening
(3)
Connect fibre optic cable accord-
5
ing to the pin assignments of the
bus IN and bus OUT fibre optic ca-
ble connections on the Anybus-S
Interbus Fibre Optic bus module
The data transmission speed is set
using the baud rate selector switch.
IMPORTANT! Set the data transmissi-
on speed before commissioning. Do
not alter the data transmission speed
during operation.
To set the desired data transmissi-
1
on speed, position the jumper as
shown.
31
