1. Attach the holder for the "Bag" external container to the device by it pushing into the guide from
above.
2. Remove the "OneWay" suction bag from
the packaging and extend it completely.
3. Insert the "OneWay" suction bag into the
"Bag" external container. Press the cover
down firmly at the edges to ensure that the
seal is good.
4. Attach the pre-assembled connecting tube
of the "OneWay" suction bag to the bottom
end of the T-piece on the external
container.
Names of connections
A vacuum port
B patient port
Fig. 7
Fig. 8
Fig. 9
Fig. 10
