5 Icons and terms
5.1 Icons on the device, packaging and accessories
Observe the icons on the device, the packaging and the accessories.
SYMBOLS THAT IDENTIFY THE MEDICAL DEVICE AND ACCESSORIES
Illustration Meaning
Manufacturer
Distribution partner
Catalogue number
Batch number
INSTRUCTIONS FOR WORKING WITH THE MEDICAL DEVICE AND ITS ACCESSORIES
Illustration Meaning
Follow the directions of the
instructions for use.
Observe the instructions for
use.
Specifies the adjustable
operating and rest times.
Do not use if packaging is
damaged!
The product is intended solely
for single use.
The product is intended for
reuse on a single patient.
Power supply unit
Illustration Meaning
Date of manufacture with
country of manufacture
The product is a medical
device.
Serial number
Unique device identification
Illustration Meaning
The applied part of the device
is classified as Type BF.
(Body Floating)
Protection type: IP33:
The device is protected from
the ingress of solid foreign
bodies ≥ 2.5 mm diameter
and from water spray from all
directions, including is the
device is tilted 60° from
vertical.
Power range of the suction
device:
Low volume flow
(< 20 l/min),
Average vacuum (between 20
kPa and 60 kPa)
