The aScope 5 Broncho has been assessed as compatible with the following endotracheal tube
(ETT) and endotherapy instrument (EI) sizes:
aScope 5 Broncho 2.7/1.2
aScope 5 Broncho 4.2/2.2
There is no guarantee that instruments selected solely using this working channel size will be
compatible in combination. Compatibility of selected instruments should be tested before
the procedure.
Suctioning equipment
– Suction tube of inner diameters between 5.5 mm and 9.0 mm.
2.3. aScope 5 Broncho parts
No. Part
1 Handle
2 Control lever
8
Minimum ETT
inner diameter
3.5 mm
5.0 mm
5
6
15
7
4
3
14
13
16
17
Function
Designed for left or right hand.
Moves the distal tip up or down in a single plane.
EI compatible with
a working channel of
1.2 mm
2.2 mm
2
1
8
9
10
11
12
