2. System description
The aScope 5 Broncho must be connected to an Ambu display unit. For information about
Ambu display units, please refer to the Instructions for Use of the respective display unit.
2.1. System parts
Ambu® aScope™ 5 Broncho
– Single-use device
aScope 5 Broncho 2.7/1.2 and 4.2/2.2 are not available in all countries. Please contact your local
sales office.
Product name
aScope 5 Broncho 2.7/1.2
aScope 5 Broncho 4.2/2.2
2.2. Product compatibility
The aScope 5 Broncho has been designed for use in conjunction with:
Display units
– Ambu® aBox™ 2
– Ambu® aView™ 2 Advance
Note: Connector port color and geometry on the display unit must match the connector color and geometry
on the visualization device.
Endoscopic accessories
– Passive endotherapy instruments compatible with the working channel ID (such as biopsy
forceps, cytology brushes and endoscopic needles)
– Active endotherapy instruments compatible with the working channel ID (such as cryo probe)*
– Accessories with standard Luer Slip and/or Luer Lock (using the enclosed introducer)
* aScope 5 Broncho 2.7/1.2 and 4.2/2.2 are not compatible with high frequency endotherapy instruments
and laser.
Lubricants and solutions
– Sterile water
– Isotonic saline solution
– Water based lubricants
– Noradrenaline 0.5 mg
– Local anesthetic gel and solutions, e.g:
• 1 % lidocaine solution
• 2 % lidocaine gel
• Lidocaine 10 % aerosol spray
Airway management accessories in compliance with EN ISO 5361
– Endotracheal tubes
– Laryngeal masks
– Tracheostomy tubes
– Laryngectomy tubes
– Double-swivel catheter mounts
Part numbers
624001000 aScope 5 Broncho 2.7/1.2
620001000 aScope 5 Broncho 4.2/2.2
60 cm/ 23.6"
Outer diameter [mm] "
2.7 mm / 0.11"
max 3.2 mm / 0.13"
4.2 mm / 0.17"
max 4.8 mm/0.19"
Inner diameter [mm] "
1.2 mm / 0.05"
2.2 mm / 0.09"
