Fig. 3 Drip tray and grid
1 Grid
7.3.1

Installing the blind filter and drip tray

1. Insert the blind filter.
2. Insert the grid (1, Fig. 3) in the drip tray (2, Fig. 3).
3. Place the drip tray with the recesses on the underside onto the holder
on the machine and push it in until it latches in place.
7.3.2

Installing the water filter

The water filter can optionally be acquired (see Chapter 12.1, "Spare parts and
accessories"). Install it as follows:
Fig. 4 Plan view of water tank
1 Position of water filter adapter
1. Unpack and prepare the filter cartridge according to the manufacturer's
specifications.
2. Remove the water tank lid from the top of the machine.
MOVE_BA_V1.0
Tip
The blind filter can be stored underneath the drip tray. There is
a corresponding mount for it in the drip tray holder.
2 Drip tray
1
2
1
EN - 91
