5.2.4

Operating levers

Steam tilt valve
The steam tilt valve (2, Fig. 2) is used to open and close the steam wand for
drawing hot steam.
Hot water tilt valve
The hot water tilt valve (5, Fig. 2) is used to open and close the hot water wand
for drawing hot water.
EN - 86
Starting position
The steam wand is closed.
Drawing positions (top / bottom / left / right)
The steam wand is open and hot steam is drawn.
Starting position
The hot water wand is closed.
Drawing positions (top / bottom / left / right)
The hot water wand is open and hot water is drawn.
