ENGLISH
: The connection must be
WARNING
made by authorised, skilled personnel, in
accordance with the relevant legal require-
ments, using appropriate and specifi ed ma-
terials. The appliance is supplied with oper-
ating voltage 230V1~N 50 Hz.
For direct connection to the mains one must
envisage a device that ensures disconnection
from the mains, with a contacts opening dis-
tance that ensures complete disconnection in
the conditions of category III over-tension, in
compliance with the installation rules.
: Before doing any work,
HAZARD
cut off the mains electricity supply.
Connect the appliance to the mains electricity
supply as follows:
) If not already present, install an automatic
circuit-breaker (A)
with the following characteristics:
– Thermal breaker device (to adjust see table
Annexes).
B
D
12

ELECTRICAL CONNECTION

, close to the appliance,
C
E
C
HANDLING AND INSTALLATION
– Magnetic circuit breaker curve B (IEC 60898-
1).
– Residual current protection set at a 30 mA.
Pull off the knob (B).
)
) Take out the screws(C) and take down the
dashboard (D) to access the electric box (E).
Undo the screws (F) to remove the lid (G).
)
Connect the automatic circuit-breaker (A) to
)
the appliance's terminal board
electrical mains supply, in accordance with
the electrical system diagram provided at the
back of the manual and using a cable with
the following characteristics:
– Weight: ≥ thanH05RN-F type (designation
245 IEC 57).
– Temperature of use: ≥ 70°C.
: When connecting, take
WARNING
care to connect the neutral and earth lines.
) Replace all when the operation is complete.
G
F
(H) and to the
A
H
