Conel FLOW Montage- Und Betriebsanleitung Seite 11

EN
5. Limitation of use and improper operation:
WARNING: This pump may not to be used for waste water, in particular liquids containing solids, liquids with
abrasive content as well as flammable and explosive liquids.
6. Maintenance
WARNING: Ensure that the power is disconnected before performing any service or
maintenance!
The proper function of the pump, its wear parts and its product life are mainly dependent on regular servicing and
maintenance of this unit. Particulates settle on the bottom of the tank in the course of time. This sediment can lead to
pump clogging and block the float switch. It is therefore recommended to service the pump, piping, inlets and pressure
port twice a year and, if necessary, clean the respective areas and parts. This is especially necessary in connection with
the general maintenance of the heating system prior to the start of the heating period. In the course of time and especially
after longer standstill period, particulates, at times highly acidic, can affect or destroy parts of the tank.
The upper part of the pump can be removed without the use of tools by carefully moving the 2 laces at the side part of the
pump outward. The upper part can then completely be removed and the float switch and the bottom part of the pump
body as well as the tank (bottom part) are freely accessible. These parts can now be washed with warm water and mild
soap. After cleaning, place the upper part on the lower (tank) part. A latching can be heard. Connect the pump to the
mains and fill water into the tank through one of the inlets. After having filled the tank with about 1.5 litres, the system will
start automatically and discharge the water into the sewage system.
WARNING: All points pertaining to installation and start up (see point 4) must be observed when the pump is
returned to service.
WARNING: Unit must be disconnected from the power source before servicing or
performing pump maintenance!
7 . Warranty
The warranty period for this product is 60 months from date of purchase. Proof of purchase must be provided.
Any material or manufacturing defect within this timeframe will be rectified or repaired free of cost. Any damage resulting
from misuse, in particular non-observance of the instruction manual and excessive wear and tear is excluded from the
warranty. Any unauthorised modifications or opening of the product will void the warranty.
8. Troubleshooting
Problem
Low flow rate
Motor is idle or does not start
Motor running, pump does not deliver
Pump does not operate automatically
9. Declaration of conformity
We hereby declare that the product condensate pump FLOW KP by CONEL is produced in conformity with the provisions
The following standards have been taken as a reference concerning electromagnetic compatibility:
EN 60335-1:2012-10
Probable Cause
Outlet piping clogged or kinked
Check valve contaminated
Head too large
No voltage present
Plug not plugged in
Pump blocked by mud or solids
Defective motor
Defective electronics
Outlet piping clogged or kinked
Check valve contaminated
Float switch contaminated
Micro-switch defective
CONEL GmbH
Margot-Kalinke-Strasse 9
D-80939 Muenchen
This declaration is valid for the following product:
Device type
Condensate-Pump FLOW KP
of the low voltage directive
2014/35/EU
and the directive to electromagnetic compatibility
2014/30/EU
EN 6000-6-1:2016-05
Remedy
Clean/remove kink
Clean
Reduce head
Check power supply
Plug in plug
Clean tank and pump body
Replacement by qualified personnel
Replacement by qualified personnel
Clean/remove kink
Clean
Clean
Replacement by qualified personnel
EN 6000-6-3:2011-09
11
