TECHNISCHE DATEN
9.3.2 Mapping für das GM32 allgemein
70
B E T R I E B S A N L E I T U N G | GM32
Modbus Register für Ausgabesignale, gültig für alle gemessenen Komponenten
●
Item Address
Start
Year of current time 5272
Month of current date 5273
Day of current month 5274
Hour of current time 5275
Minute of current time 5276
Second of current time 5277
Failure [collective] 5278
Maintenance required [collec- 5280
tive]
Check [collective] 5282
Out of Spec. [collective] 5284
Extended [collective] 5286
Pressure 5288
Temperature 5290
Humidity 5292
Lamp Current 5294
Lamp Integration 5296
Temperature Optic Housing 5298
Temperature Spectrometer 5300
Lamp performance 5302
Operating state 5304
Year of last Check cycle 5305
Month of last Check cycle 5306
Day of last Check cycle 5307
Hour of last Check cycle 5308
Minute of last Check cycle 5309
Second of last Check cycle 5310
LED Current 5311
LED performance 5312
Tabelle 26: Modbus „Common Out" Register
Data type Register type
Width
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
2 32 Bit integer Input register
2 32 Bit integer Input register
2 32 Bit integer Input register
2 32 Bit integer Input register
2 32 Bit integer Input register
2 32 Bit float Input register
2 32 Bit float Input register
2 32 Bit float Input register
2 32 Bit float Input register
2 32 Bit float Input register
2 32 Bit float Input register
2 32 Bit float Input register
2 32 Bit float Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
1 16 Bit integer Input register
Comment
> 2000 1)
1 – 12 1)
1 – 31 1)
0 – 23 1)
1)
0 – 59
1)
0 – 59
2)
Bit Field
3)
Bit Field
Bit Field 4)
Bit Field 5)
Bit Field 6)
Lamp pulse (mA)
Exposure (ms)
8)
> 2000 9)
1 – 12 9)
1 – 31 9)
0 – 23 9)
0 – 59 9)
0 – 59 9)
0 - 200 (mA)
0 - 100 (%)
