4.6

Tabular representation

For all weekly, holiday, annual and astro programs, all the information of a
timer program is shown in the table. Each switching command
(e.g. ON or OFF) is shown in a table column.
4.6.1 Weekly program
Program number of the switching commands
A
Type of switching command (ON, OFF, Pulse, Cycle ON or Cycle OFF)
B
Time
C
Start or End Time of the switching command
Pulse duration
D
The pulse duration shows the ON switching time of a switching
command in case of a pulse or cycle program.
Period
E
The period shows the duration of a cycle.
Weekday
F
You can select the weekday on which the respective timer program
is to be started or finished. Tick the "Daily" box if the switching
command should be carried out every day.
86
If you click with the left mouse button on a switching command in the table,
this command is highlighted.
If you click with the right mouse button, a menu opens. Select Delete to
delete the timer program.
To change the time, pulse duration or period of a switching command, click
on the desired switching command in the table with the left mouse button.
The "up" and "down" arrow keys
(hh), minutes (mm) and seconds (ss).
A B C
Abb. 14: Tabular representation – Weekly program
can be used to set days (dd), hours
D E F
