13. Transmitting timer programs via the handheld programming device

The handheld programming device can be used to transmit the timer programs
created by means of the PC to the respective timer and vice versa.
You can transmit the respective timer program exclusively to the
timer (model) for which the timer program was created.
138

13.1 Transmission principle

The data is transmitted from the PC to the handheld programming device and
vice versa via the serial interface to which the handheld programming device is
connected (COMX).
The data is transmitted from the handheld programming device to the respective
timer via an infrared interface or downloaded from the timer by the handheld
programming device.
The same method is used to transmit the timer programs from timer to timer.
IR interface
Handheld programming device
PC interface
At the end of this chapter, you will find some information from the operating
manual of the handheld programming device.
For further information, see the separate operating manual "Handheld
programming device".
1 6 12 18 24 1 6 12 18 24
C1
15 : 26 15:26
OVR
FIX
ON 2
1 OFF ON 2 1 OFF
MENU
MENU
2 1 2
1 Res.
