8.2 Weekly program – Pulse
Example
Channel 1 is to be switched ON from Monday to
Friday at 03:00 p.m.
The ON switching duration is 15 minutes.
Starting the program
1. Start the program and select your timer (see chapter 3).
The main menu opens.
 Z
2. In the register, click on the button Weekly Programs.
3. Select in the register the Channel for which you want to create the weekly
program, e.g. CH1 = channel1.
It is possible to specify channels by double-clicking on the Channels tab.
Pulse programming
4. Select the switching command
5. Click with the left mouse button in the line for Monday on the field 03:00 p.m.
to set the ON switching command.
The window "Pulse/Cycle Settings" opens.
 Z
6. Set the minutes and seconds for the pulse duration and confirm your input by
clicking on OK.
102
.
2.
3.
Abb. 26: Weekly program - Pulse
4.
5.
6.
Abb. 27: Weekly program - Pulse 2
