Instructions for Use
microStop® – MiniSet Container System
Coding Labels and Logistics Framelet
The two container front plates (2) also feature a slot section (4) where a coding label (1) can be attached.
Laser-lettered coding labels with customized information concerning tray contents and destination are
available from Gebrüder Martin on request.
An additional coding label can be optionally attached to the container cover (5), together with a logistics
frame (3). This label can also be laser-lettered by the manufacturer in accordance with the customer's
specifications. The logistics frames are available in nine different colors, to be used for assignment to
specific medical fields.
Log Labels or Cards
Both front plates (2) of the container feature a slot section (4) with a retaining spring for accommodating
and fixing universal log labels. An additional slot section (6) with a retaining spring is available on the cover,
which can also be used for log or barcode labels.
4.1.2

Materials Used

Designation
Stainless steel
Plastics
Aluminum
Other materials
4.1.3

Combination products and accessories

REF
04-049-00-06
04-049-00-08
55-867-00-04
55-861-90-98
55-861-05-04
55-861-03-04
55-861-04-04
55-864-01-04
55-864-02-04
55-864-05-04
55-864-06-04
55-864-10-04
55-864-11-04
55-864-12-04
55-864-13-04
Revision 04
International name
X10CrNi18-8, 1.4310; X5CrNi1810, 1.4301
PPSU; PEEK; Silicone
Al99,0, 3.0205;
AlMgSi1 F28 EN AW-6082
Designation
Holding bracket on panel for label, MiniSet
Holding bracket on cover for label, MiniSet
microStop disk, yellow
Fitting for microStop MiniSet container
Cover for MiniSet cont. 55-861-50 / -70
Box for MS MiniSet container, H = 52 mm
Box for MS MiniSet container, H = 72 mm
Coding label, MS1, with text, no hole
Coding label, MS1, no text, no hole
Coding label, MiniSet, with text
Coding label, MiniSet, no text
Logistics frame, black
Logistics frame, white
Logistics frame, red
Logistics frame, blue
31
