Positioning the footboard
Proceed as outlined below.
1) Loosen the nuts (A).
2) Move the footboard (B) into the most
comfortable position.
3) Tighten the nuts (A).
Plant changeover
The distance between one seedling and the next (plant
spacing) depends on the pinions engaged in the Rapid
Shift gearbox.
EQUIPMENT PACKAGE 14 - 50 RAPID SHIFT - FRAME
Plant spacing
cm inches z 1 z 2 z 3 z 4 z 5 z 6 z 7 z 8
14 5 - 1/2
17 6 - 3/4
20 7 - 7/8
22 8 - 5/8
24 9 - 1/2
26 10 - 1/4
28 11
17
31 12 - 3/8
34 13 - 3/8
37 14 - 5/8
40 15 - 3/4
42 16 - 1/2
45 17 - 3/4
50 19 - 3/4
EQUIPMENT PACKAGE 14 - 50 RAPID SHIFT - WHEEL
Plant spacing
cm inches z 1 z 2 z 3 z 4 z 5 z 6 z 7 z 8
14 5 - 1/2
17 6 - 3/4
20 7 - 7/8
22 8 - 5/8
24 9 - 1/2
26 10 - 1/4
28 11
17
31 12 - 3/8
34 13 - 3/8
37 14 - 5/8
40 15 - 3/4
42 16 - 1/2
45 17 - 3/4
50 19 - 3/4
English language
INFORMATION FOR USE
UN41-0908UA
N. pinions
14 -
17 17 17 17
- 20
N. pinions
14 -
22 13 20 16
- 20
The tables show the possible distances between one
seedling and the next that can be obtained with the
Rapid Shift gearbox.
28
28 26 22
26
22
20
19
17
16
20
z 1
19
17
16
15
14
13
UN41-0909UA
28
26
28 26 22
22
20
19
17
16
20
z 1
19
17
16
15
14
13
UN41-0910UA
22
A
z 2 z 3
20 19 17 16 15 14
z 8
z 6
z 7
z 2 z 3
20 19 17 16 15
14
z 8
z 6
z 7
Use and maintenance
6
B
13
z 4
z 5
13
z 4
z 5
