Data connections
Internal test box:
Dimensions (LxWxH)
Weight
Power supply
Power consumption:
Operation environment
Transport and storage
Affinity2.0/Equinox2.0 – Instructions for Use - EN
Left, Right
Ins. Left, Ins. Right
Bone
Ins. Mask.
HF/HLS
Insitu L, Insitu R
Monitor, Ass. Mon.
Sp. 1-4 Power Out
DC
TB Loop
FF Loop
Batt. Sim.
Batt. Sim. - Internal TB
(Affinity2.0 only)
USB/PC
USB
Keys.
Built in test box holds telecoil drive as well as special dual speaker set f or
checking directional microphone f unction.
Af f inity2.0:
Af f inity2.0:
100-240 V~, 50-60Hz
195VA
Temperature:
Re. Humidity:
Ambient pressure range:
Transport temperature:
Storage temperature:
Re. Humidity:
Up to 7.0Vrms by 10Ω load
70Hz-20kHz ±3dB
Max.3.5Vrms. by 8 Ω load
70Hz-20kHz ±3dB
Voltage: 5VDC
Current: 0.5A
Up to 100mA/meter
70Hz-20kHz ±3dB
Voltage: 1.1 – 1.6VDC
Impedance range: 0 – 25 Ω.
USB B socket f or connection to PC
(Compatible with USB 1.1 and later)
USB A socket f or connection of other USB
devices
(Internal USB 1.1 hub)
Serial Peripheral Interf ace Bus (SPI
interf ace)
Check the Service Manual f or more
inf ormation.
42 x 38 x 14 cm / 16.5 x 15 x 5.5 inches
5.5 kg / 12.1 lbs.
15-35°
30-90% Non-condensing
98kPa o 104kPa
-20-50°C
0-50°C
10-95% Non-condensing
