PULLALIGN technical data

Laser units ALI 2.100 (red laser) and ALI 2.131 (green laser)
Type
Beam power
Beam divergence
Beam spread
Maximum beam power
Wavelength
Safety class
Safety precautions
Measuring accuracy
Measuring distance
Power supply
Operating time
Controls
Operating temperature
Storage temperature
Mounting method
Weight
Dimensions
Housing material
Reflector ALI 2.300
Accuracy
Reflector surface size
Mounting method
Weight
Dimensions
Housing material
Targets (non-adjustable) ALI 2.302
Quantity
Mounting method
Weight
Dimensions
Housing material
Targets (adjustable) ALI 2.303
Quantity
Mounting method
Weight
Dimensions
Housing material
Semiconductor laser diode
< 1.0 mW (according to IEC 60825-1:2014 condition 3)
< 1.0 mrad
70 deg.
< 3.0 mW
ALI 2.100 — 630 – 680 nm (red visible)
ALI 2.131 — 505 – 535 nm (green visible)
Class 2 according to IEC 60825-1:2014
The laser complies with 21 CFR 1040.10 and 1040.11
except for deviations pursuant to Laser Notice No. 50,
dated June 24, 2007.
Do not look into the laser beam
0.2°
10 m between units
4 AAA alkaline batteries
ALI 2.100 — 25 hours; ALI 2.131 — 17 hours
ON/OFF rocker switch
-5°C to 40°C (23°F to 104°F)
-10°C to 70°C (14°F to 158°F)
Strong magnets
Approx. 0.3 kg (0.66 lb.) with batteries
Approx. 37 x 40 x 170 mm (1 7/16" x 1 9/16" x 6 11/16")
ALI 2.100 — Red anodized aluminium
ALI 2.131 — Red anodized aluminium
0.2°
21 x 32 mm (13/16" x 1 1/4")
Strong magnets
Approx. 0.27 kg (0.6 lb)
Approx. 37 x 40 x 170 mm (1 7/16" x 1 9/16" x 6 11/16")
Red anodized aluminium
3
Strong magnets
Approx. 40 g (1.4 oz) per target
Height including magnetic base approx. 55 mm (2 11/64")
Base diameter approx. 20 mm (25/32")
Red anodized aluminium
3 – adjustable over 12.7 mm (1/2")
Strong magnets
Approx. 35 g (1.2 oz) per target
Height including magnetic base approx. 45 mm (1 49/64)
Base diameter approx. 20 mm (25/32")
Gray anodized aluminium
