15. Charging station diagnostic

15.1. Introduction

The charging station incorporates a set of control parameters to establish a diagnosis during all phases of its operation.
The results are provided in the B1280 diagnose .txt file when the USB flash drive is inserted into the USB port of the charging station controller
board.
The B1280 diagnose .txt file is made up of 2 areas:
1. A first area providing all of the charging station configuration parameters from the [Config] field to the [Tic] field. For more details, refer to
Chapter 11: Charging station Configuration.
2. A second area providing a complete diagnosis of the charging station and starting with the [Diagnose] field.
DANGER WARNING: if a live diagnosis is required, please equip yourself with PPE (Personal Protective Equipment).

15.2. Diagnostic parameters and their explanations

This chapter sets out the diagnostic function of the B1280 controller board.
Description:
The diagnostic function is implemented to provide detailed information on the current state of the charging station.
• The diagnostic is written automatically when the USB flash drive is inserted.
• On a B1280 controller, equipped with an optional XEVA220 Wi-Fi card, access is via the Wi-Fi network instead of USB.
The diagnostic information is divided into sections, each of which is described below.
Each section may vary depending on the configuration of the Witty charging station.
Example of a Diagnose function:
The parameters of the Diagnose function cannot be modified
15.2.1. Information
This section concerns the current software version, the type of board and other charging station data.
[Information]
Version = 7.0.1.0
Hardware = B1280
D/N_Timer = 0 s
Blackout_timer = 0 s
Wifi = absent
Field Possible value
Version = x.x.x.x
Hardware = B1280
D/N_Timer = Minutes
Blackout_timer = 0-60 Seconds
Wifi = Absent; Present
15.2.2. Inputs
This section deals with the current status of the input data.
[Inputs]
Slider = Delayed inclusive
Current_selector = 32 A
Tariff = High tariff
CHP_Input = Open (unused)
Temp = 27°C
Key_Switch = Unlocked
Installation_phases = Three-phase
48
Note
Witty charging station software version
The current status of the D/N timer, if not at zero, represents the time remaining in minutes before
charging begins.
Current value of the blackout timer after a power failure. If it is not zero, it represents the time
remaining in seconds before charging restarts.
