hager Witty Installationsanleitung Seite 50

15.2.4. TIC
This section concerns the communication protocol between the main meter and the charging stations
[TIC]
Activity = Active
Data = Valid (24587)
Mode = History
Isousc = 45 A
Iinst = 1 A
Tariff = HP. (High tariff)
Field Possible value
Activity Inactive; Active
Data Invalid; Valid
Mode "Standby
Standard
History
Three-phase
standard
Three-phase
history
Greencharging
Unknown"
Iprod n A
Isousc n A
Iinst n A
Iinst_x n A
Tariff
HC..
HCJB
HCJR
HCJW
HN..
HP..
HPJB
HPJR
HPJW
PM..
TH..
Tariff1
Tariff2
Tariff3
Tariff4
Tariff5
Tariff6
Tariff7
Tariff8
Tariff9
Tariff10
15.2.5. Error
[Error]
err_1: No error
err_2:
Field Possible value
"err_x "
(x is the number of the: No Error""
- socket 1 / T2S socket Cable Failure""
or CP Short Circuit Failure""
- socket 2 / TE socket Over Consumption""
E.g.: 1, 2)" Ventilation Error""
Load Shedding Failure""
CP Failure""
DC Current Failure""
Welded Contact Failure 1""
DC Sensor Failure"""
50
Note
Inactive; Active ➞ Active means that a frame has been received
Invalid; Valid ➞ Valid means that the TIC frame is correct
Standby
Single-phase standard
Single-phase history
Three-phase standard
Three-phase history
Greencharging
Unknown
n is the current produced. Only displayed if Ecolo = Active
n is the maximum subscribed current. Only displayed if Ecolo = Inactive
n is the instantaneous current consumed by the installation. Only displayed if Ecolo = Inactive
n is the instantaneous current consumed by the installation during phase x. Only displayed with
a three-phase TIC
.. If 2 points are present behind a rate, it is followed by the wording Low (advantageous cost)
or High (normal/high cost)
HC/HP tariff: Off peak hours
Tempo tariff: Off peak hours, blue day
Tempo tariff: Off peak hours, red day
Tempo tariff: Off peak hours, white day
Normal hours tariff
HP/HC tariff: Peak hours
Tempo tariff: Peak hours, blue day
Tempo tariff: Peak hours, red day
Tempo tariff: Peak hours, white day
EJP tariff: Mobile peak hours
Hourly tariff
Tariff1 to Tariff10 only supplied by the Linky meter in standard TIC.
The tariffs used depend on the tariff contract selected by the customer, depending on their energy
supplier.
Note
"In the event of an error, the number of flashes is also specified so that the LED
error code is known (see Chapter 16. Indicators).
No Error
Cable Failure
CP Short Circuit Failure
Over Consumption
Ventilation Error
Load Shedding Failure
CP Failure
DC Current Failure
Welded Contact Failure 1
DC Sensor Failure"
