Identification Label; Description Of The Exterior - hager Witty Installationsanleitung

2 locking keys to secure
access to the
charging station
and located
inside the
charging station.
EV Charging Station
Witty
C
Identification
label
1 phase AC : 7 kW

3. Description of the exterior

• Exterior
Lighting strip
Hover button
Location of user sticker
Frame
Location for cable
support
Cover opening
32
Up
Down
x 4
x 2
x 8
x 4
x 4
x 4
x 1
Ref.: XEVA100
Refer to the
instructions
provided with
the cable sup-
port to install it.
Optional
8
Mode 3 socket
T2/T2S
Charging station lock
x 6
T25S
T30
10
